Specifications
- Manufacturer: Harley-Davidson
- Model: Deadwood™
- Year: 2026
- Type: Cruiser
- Length: 2,410 mm (94.8819 in.)
- Overall Width: 930 mm (36.6142 in.)
- Overall Height: 1,275 mm (50.1969 in.)
- Seat Height, Laden: 648 mm (25.5118 in.)
- Seat Height, Unladen: 673 mm (26.4961 in.)
- Static Ground Clearance: 120 mm (4.7244 in.)
- Rake (steering head): 30
- Fork Angle: 30
- Trail: 147 mm (5.7874 in.)
- Wheelbase: 1,630 mm (64.1732 in.)
- Tires, Type: Dunlop® Harley-Davidson Series, bias blackwall front and rear
- Tires, Front Model: D401F
- Tires, Front Specification: 130/90B16,73H,BW
- Tires, Rear Model: D401T
- Tires, Rear Specification: 150/80B16,77H,BW
- Fuel Capacity: 18.9 l (4.9934 gal.)
- Reserve Fuel Capacity, Fuel Injection (warning light): 3.8 l (1.004 gal.)
- Oil Capacity (w/filter): 4.7 l (4.9683 qt.)
- Transmission Capacity: 1 qt. (.95 l )
- Primary Chain Case Capacity: 1.25 qt. (1.18 l )
- Coolant Capacity: N/A
- Weight, As Shipped: 298 kg (656.9665 lb.)
- Weight, In Running Order: 311 kg (685.6261 lb.)
- Gross Vehicle Weight Rating: 526 kg (1,159.612 lb.)
- Gross Axle Weight Rating, Front: 204 kg (449.7354 lb.)
- Gross Axle Weight Rating, Rear: 331 kg (729.7178 lb.)
- Luggage Capacity -Volume: N/A
- Engine: Milwaukee-Eight® 117 Classic
- Valves: Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; four valves per cylinder
- Bore: 4.075 mm (0.1604 in.)
- Stroke: 4.5 mm (0.1772 in.)
- Displacement: 117 cc (7.1398 cu in)
- Compression Ratio: 10.3:1
- Fuel System: Electronic Sequential Port Fuel Injection (ESPFI)
- Air Cleaner: 9 in. (229 mm) round, center bolt cover with washable fiberglass filter media
- Exhaust: 2-into-1; catalyst in header
- Lubrication System: Pressurized, dry-sump with oil cooler
- Primary Drive: Chain, 34/46 ratio
- Final Drive: Belt, 32/66 ratio
- Clutch: Mechanical, 10 plate wet, assist & conventional
- Transmission: 6-Speed Cruise Drive®
- Gear Ratios (overall) 1st: 9.311
- Gear Ratios (overall) 2nd: 6.454
- Gear Ratios (overall) 3rd: 4.793
- Gear Ratios (overall) 4th: 3.882
- Gear Ratios (overall) 5th: 3.307
- Gear Ratios (overall) 6th: 2.79
- Frame: Mild steel, tubular frame; rectangular section backbone; stamped, cast, and forged junctions; MIG welded; aluminum forged fender supports
- Swingarm: Mild steel, tubular sections, stamped x-member, forged axle junctions; MIG welded; removable belt spacer
- Front Fork: Dual-bending valve 49 mm telescopic with aluminum fork triple clamps; dual rate spring; "beer can" covers
- Rear Shocks: Hidden, free piston, coil-over monoshock; 43mm stroke; cam-style preload adjustment
- Wheels, Optional Style Type: N/A
- Wheels, Front Type: Black Tubeless Laced w/ 36 Bright Spokes
- Wheels, Front Diameter: 16 in. (406 mm)
- Wheels, Front Width: 3 in. (76 mm)
- Wheels, Rear Type: Black Tubeless Laced w/ 36 Bright Spokes
- Wheels, Rear Diameter: 16 in. (406 mm)
- Wheels, Rear Width: 3 in. (76 mm)
- Brakes, Caliper Type: 4-piston fixed front and 2-piston floating rear
- Brakes, Rotor Type: Solid, uniform expansion rotors
- Brakes, Front Diameter: 300 mm (11.811 in.)
- Brakes, Front Thickness: 5 mm (0.1969 in.)
- Brakes, Front is dual: No
- Brakes, Rear Diameter: 292 mm (11.4961 in.)
- Brakes, Rear Thickness: 5.8 mm (0.2283 in.)
- Brakes, Anti-Lock Braking System (ABS): Standard
- Suspension Travel, Front: 130 mm (5.1181 in.)
- Suspension Travel, Rear: 86 mm (3.3858 in.)
- Engine Torque Testing Method: J1349
- Engine Torque: 163 Nm (120.2242 ft-lb)
- Engine Torque (rpm): 2,500
- Power (Hp/kW): 98 HP / 73 kW @ 4600 rpm
- Lean Angle Testing Method: J1168
- Lean Angle, Right: 27
- Lean Angle, Left: 27
- Fuel Economy Testing Method: Estimated City/Hwy
- Fuel Economy: 5 l/100 km (47.04 mpg)
- CO2 Emissions Testing Method: N/A
- CO2 Emissions: N/A
- Stationary Noise (BRZ only): N/A
- Battery: Sealed, maintenance-free, absorbed glass mat (AGM) battery, 12V, 17.5Ah, 310 CCA at 0°F
- Charging: Three-phase, 48 Amp system (364 Watts @13 Volts, 900 rpm, 624 Watts max power @ 13 Volts, 2000 rpm)
- Starting: 1.6 kW electric with solenoid shift starter motor engagement
- Lights (as per country regulation), Headlamp: All LED, low beam, high beam and signature position lamp
- Lights (as per country regulation), Tail/Stop: LED Buffett tail lamp
- Lights (as per country regulation), Front Signal Lights: LED Bullet Turn Signals
- Lights, Rear Turn Signals: LED bullet light bar
- Gauges: 5-inch (127 mm) analog speedometer with digital gear, odometer, fuel level, ride modes, heated gear, traction control, ABS, TPMS, cruise control, clock, trip, range and tachometer indication
- Auxiliary Lamps: LED fog
- Electric Power Outlet: USB C-Type , Output 5V at 2.4 Amp
- GPS System: N/A
- Reverse: N/A
- EV Specific Content: Motor: FLHD Deadwood™
- EV Specific Content: RESS: FLHD Deadwood™
- EV Specific Content: Charging: FLHD Deadwood™
- EV Specific Content: Range: FLHD Deadwood™
- LiveWire: Experience: FLHD Deadwood™
- LiveWire: Telematics: FLHD Deadwood™
- Warranty: 24 months (unlimited mileage)
- Service Interval: First 1,000 miles (1,600 km), every 5,000 miles (8,000 km) thereafter
- 1: Vehicles depicted may differ from vehicles manufactured and delivered. Specifications and prices listed may differ from specifications and prices of vehicles manufactured and delivered. All product descriptions (including depictions, specifications, dimensions, measurements, ratings and competitive comparisons) are based on available information at the time of publication. Although such descriptions are believed correct, errors and changes can occur and complete accuracy cannot be guaranteed. Harley-Davidson may make changes at any time to prices and specifications, and may change or discontinue models, without notice and without incurring any obligation. Attention: Vehicles in the configurations shown and many of the accessories described in this catalog may not be available for sale or use in some locations. Please check with your dealer for complete product details and the latest information. All models feature 6-speed transmission (VRSC™ models and Sportster® models are 5-speed) and carbon fiber belt final drive; multi-plate clutch with diaphragm spring in oil bath; and 2-year unlimited mileage warranty.
- 2: Measurement reflects 180 lb. (81.7 kg) operator weight.
- 3: Recommended 91 octane or higher fuel (R+M)/2.
- 4: Standard and optional wheels may vary by country and region.
- 5: Values shown are nominal. Performance may vary by country and region.
- 6: See motorcycle owner’s manual for complete details.
- 7: Inspections of certain systems and components are required at 2,500 mile (4,000 km) intervals. See Owner’s Manual for full details.
- 8: Limited availability. See your dealer for details and available colors.
- 9: North America security system includes immobilizer; outside North America the security system includes immobilizer and siren.
- 10: Availability of colors may vary from dealer to dealer, and is subject to change without notice. Custom Color options have limited availability. See your dealer for details and available colors.
