Specifications
- Manufacturer: Harley-Davidson
- Model: Super Glide®
- Year: 2026
- Type: Cruiser
- Length: 2,320 mm (91.3386 in.)
- Overall Width: 925 mm (36.4173 in.)
- Overall Height: 1,160 mm (45.6693 in.)
- Seat Height, Laden: N/A
- Seat Height, Unladen: 665 mm (26.2 in.)
- Static Ground Clearance: 125 mm (4.9213 in.)
- Rake (steering head): 30
- Fork Angle: 30
- Trail: 157 mm (6.1811 in.)
- Wheelbase: 1,630 mm (64.1732 in.)
- Tires, Type: Dunlop® Harley-Davidson Series, bias blackwall front and rear
- Tires, Front Model: D401F
- Tires, Front Specification: 100/90B19,57H,BW
- Tires, Rear Model: D401T
- Tires, Rear Specification: 150/80B16,77H,BW
- Fuel Capacity: 13.2 l (3.4875 gal.)
- Reserve Fuel Capacity, Fuel Injection (warning light): 3.8 l (1.004 gal.)
- Oil Capacity (w/filter): 4.7 l (4.9683 qt.)
- Transmission Capacity: 1 qt. (.95 l )
- Primary Chain Case Capacity: 1.25 qt. (1.18 l )
- Coolant Capacity: N/A
- Weight, As Shipped: 282 kg (621.6931 lb.)
- Weight, In Running Order: 293 kg (645.9436 lb.)
- Gross Vehicle Weight Rating: 526 kg (1,159.612 lb.)
- Gross Axle Weight Rating, Front: 204 kg (449.7354 lb.)
- Gross Axle Weight Rating, Rear: 331 kg (729.7178 lb.)
- Luggage Capacity -Volume: N/A
- Engine: Milwaukee-Eight® 117 Classic
- Valves: Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; four valves per cylinder
- Bore: 103.5 mm (4.0748 in.)
- Stroke: 114.3 mm (4.5 in.)
- Displacement: 1,923 cc (117.3491 cu in)
- Compression Ratio: 10.3:1
- Fuel System: Electronic Sequential Port Fuel Injection (ESPFI)
- Air Cleaner: 9 in. (229 mm) round, center bolt cover with washable fiberglass filter media
- Exhaust: 2-into-1; catalyst in header
- Lubrication System: Pressurized, dry-sump with oil cooler
- Primary Drive: Chain, 34/46 ratio
- Final Drive: Belt, 32/66 ratio
- Clutch: Mechanical, 10 plate wet, assist & conventional
- Transmission: 6-Speed Cruise Drive®
- Gear Ratios (overall) 1st: 9.311
- Gear Ratios (overall) 2nd: 6.454
- Gear Ratios (overall) 3rd: 4.793
- Gear Ratios (overall) 4th: 3.882
- Gear Ratios (overall) 5th: 3.307
- Gear Ratios (overall) 6th: 2.79
- Frame: Mild steel, tubular frame; rectangular section backbone; stamped, cast, and forged junctions; MIG welded; aluminum forged fender supports
- Swingarm: Mild steel, tubular sections, stamped x-member, forged axle junctions; MIG welded; removable belt spacer
- Front Fork: Dual-bending valve 49 mm telescopic with aluminum fork triple clamps; dual rate spring; gaiter covers
- Rear Shocks: Hidden, free piston, coil-over monoshock; 43mm stroke; cam-style preload adjustment
- Wheels, Optional Style Type: N/A
- Wheels, Front Type: Chrome aluminum tubeless laced wheel
- Wheels, Front Diameter: 19 in. (483 mm)
- Wheels, Front Width: 2.5 in. (64 mm)
- Wheels, Rear Type: Chrome aluminum tubeless laced wheel
- Wheels, Rear Diameter: 16 in. (406 mm)
- Wheels, Rear Width: 3 in. (76 mm)
- Brakes, Caliper Type: 4-piston fixed front and 2-piston floating rear
- Brakes, Rotor Type: Solid, uniform expansion rotors
- Brakes, Front Diameter: 300 mm (11.811 in.)
- Brakes, Front Thickness: 5 mm (0.1969 in.)
- Brakes, Front is dual: No
- Brakes, Rear Diameter: 292 mm (11.4961 in.)
- Brakes, Rear Thickness: 5.8 mm (0.2283 in.)
- Brakes, Anti-Lock Braking System (ABS): Standard
- Suspension Travel, Front: 130 mm (5.1181 in.)
- Suspension Travel, Rear: 86 mm (3.3858 in.)
- Performance: FXD Super Glide®
- Engine Torque Testing Method: J1349
- Engine Torque: 163 Nm (120.2242 ft-lb)
- Engine Torque (rpm): 2,500
- Power (Hp/kW): 98 HP / 73 kW @ 4600 rpm
- Lean Angle Testing Method: J1168
- Lean Angle, Right (deg.): 28.5
- Lean Angle, Left (deg.): 28.5
- Fuel Economy Testing Method: Estimated City/Hwy
- Fuel Economy: 5 l/100 km (47.04 mpg)
- CO2 Emissions Testing Method: N/A
- CO2 Emissions: N/A
- Stationary Noise (BRZ only): N/A
- Battery: Sealed, maintenance-free, absorbed glass mat (AGM) battery, 12V, 17.5Ah, 310 CCA at 0°F
- Charging: Three-phase, 48 Amp system (364 Watts @13 Volts, 900 rpm, 624 Watts max power @ 13 Volts, 2000 rpm)
- Starting: 1.6 kW electric with solenoid shift starter motor engagement
- Lights (as per country regulation), Headlamp: All LED, low beam, high beam and signature position lamp
- Lights (as per country regulation), Tail/Stop: Bullet-style, LED stop/tail/turn signals
- Lights (as per country regulation), Front Signal Lights: LED Bullet Turn Signals
- Lights, Rear Turn Signals: LED Bullet Turn Signals
- Gauges: 5-inch (127 mm) analog speedometer with digital gear, odometer, fuel level, ride modes, heated gear, traction control, ABS, TPMS, cruise control, clock, trip, range and tachometer indication
- Auxiliary Lamps: N/A
- Electric Power Outlet: USB C-Type , Output 5V at 2.4 Amp
- GPS System: N/A
- Reverse: N/A
- EV Specific Content: Motor: FXD Super Glide®
- EV Specific Content: RESS: FXD Super Glide®
- EV Specific Content: Charging: FXD Super Glide®
- EV Specific Content: Range: FXD Super Glide®
- LiveWire: Experience: FXD Super Glide®
- LiveWire: Telematics: FXD Super Glide®
- Infotainment system: N/A
- Screen Size: N/A
- Type: N/A
- Watts Per Channel: N/A
- Speakers: N/A
- Speaker Size: N/A
- Headset Specifications (if equipped): N/A
- AM: N/A
- FM: N/A
- MW: N/A
- LW: N/A
- Weather Band (WB): N/A
- SD Card, Flash Drive and MP3 - via USB Connection: N/A
- Languages: N/A
- Hands-free Mobile Phone - via Bluetooth: N/A
- Voice Recognition Languages: Phone functions only: N/A
- Voice Recognition Languages: Tuner/Media/Navigation: N/A
- Rider/Passenger Intercom: N/A
- Vehicle Information Screen (Air temperature, oil pressure and EITMS): N/A
- Text-to-Speech (TTS) Languages: N/A
- USB: N/A
- Phone Connectivity: N/A
- Bluetooth: N/A
- Navigation: N/A
- Warranty: 24 months (unlimited mileage)
- Service Interval: First 1,000 miles (1,600 km), every 5,000 miles (8,000 km) thereafter
